Apex Teleoperation Configuration Changes

This page covers customer-accessible configuration for delivered Marvin Pro, Gento Skye, and Gento Luna systems. Package layouts, controllers, and end effectors may differ between releases. Always use the delivery checklist and installed version as the source of truth.

Before making changes

• Stop teleoperation and recording, and place the robot in a safe state.
• Back up the original file, change one category at a time, and perform no-motion checks first.
• Do not replace the current configuration with a complete file from another model or delivery batch.
• Control gains, QP parameters, collision models, and calibration data are not customer settings and must not be changed without technical support.

Default Controller Login Credentials

Controller	Default IP	Username	Default password
Tianzhun	6.6.7.100	nvidia	nvidia
Lingjing Thor	6.6.7.100	user	1

These values are factory defaults only. Use the delivery configuration when networking or credentials have been changed. Do not expose controller SSH directly to the public Internet. Before changing a default password, confirm that the change will not affect automated deployment, remote maintenance, or delivery scripts.

1. Identify the Active Configuration

Configuration files may exist in both source and installation directories. Running services normally use the installation directory, so confirm the active service and package paths first.

source /etc/apex/apex_ros_env.sh

ros2 pkg prefix marvin_ros_control
ros2 pkg prefix marvin_teleop
ros2 pkg prefix marvin_qp_controller

systemctl cat apex-robot.service
systemctl cat apex-teleop.service
systemctl cat apex-camera.service

Inspect the global configuration:

grep -Ev '^\s*(#|$)' /etc/apex/apex.env

If a package or service is absent, follow the names used on that delivered system. Do not create a replacement service with the example name.

2. Back Up and Edit a File

Replace CONFIG_FILE with the confirmed path:

CONFIG_FILE=/actual/path/config.yaml
sudo cp "$CONFIG_FILE" "${CONFIG_FILE}.bak.$(date +%Y%m%d_%H%M%S)"
sudoedit "$CONFIG_FILE"

Use spaces, not tabs, in YAML files. Do not edit the generated /etc/apex/dnsmasq.conf or manually change /etc/apex/apex_ros_env.sh.

3. Customer-Accessible Settings

3.1 Global Environment

The global configuration file is /etc/apex/apex.env.

Setting	Purpose	Requirement
ROS_DOMAIN_ID	ROS 2 communication domain	Must match on every controller, workstation, and development computer that communicates with the system
ROS_LOCALHOST_ONLY	Restricts ROS 2 to the local host	Set to 0 for communication between devices
APEX_DNSMASQ_INTERFACE	Interface used by the headset/control network	Must be an interface that exists on the system
APEX_DNSMASQ_HOST_IP	Host address of the DHCP interface	Must match the static IP assigned to that interface
BAG_STORAGE_ROOT	Recording destination	The directory or mounted drive must exist and be writable
APEX_TOOL_TYPE	End-effector type	Common values are dm, zy, and none; it must match the installed hardware and package
APEX_TELEOP_MODE	Teleoperation input mode	Common values are controller and dexhand; use the delivered configuration
APEX_GLOVE_MODE	Glove mode	Enable only when the matching glove and software are installed
APEX_USE_RVIZ	Starts RViz with the service	Normally remains false on delivered systems

Customers may inspect the following product-identification values, but should contact technical support before changing them:

• APEX_ROBOT_PLATFORM: product platform, such as pro or gento.
• APEX_COMPUTE_PLATFORM: compute platform; supported values depend on the release.
• APEX_ROBOT_MODEL: robot model. Skye and Luna configurations are not interchangeable.
• APEX_ROS_SETUP and APEX_WS_SETUP: ROS and workspace setup paths; do not change during normal operation.

3.2 Robot Address

Robot-control configuration is normally stored under:

/opt/kernelmind/apex/install/marvin_ros_control/share/marvin_ros_control/config/

The robot_ip value must match the robot controller's actual address. Addresses can differ between products and delivery batches, so do not reuse an example IP from another system. Verify network reachability before restarting Robot and then Teleop.

Customers must not change the control rate, joint order, feed-forward settings, Kp/Kd values, or end-effector dynamics.

3.3 Headset and ROS 2 Network

Check all of the following when changing network settings:

1. The headset, controller, and workstation use the planned subnet.
2. APEX_DNSMASQ_INTERFACE is the physical port connected to the headset network.
3. APEX_DNSMASQ_HOST_IP matches the static address on that port.
4. All communicating devices use the same ROS_DOMAIN_ID.
5. ROS_LOCALHOST_ONLY=0 for communication between devices.

Changing only the DHCP pool without assigning a static address from the same subnet to the selected interface prevents the DHCP service from listening on that interface. Use the delivered wiring guide and network table for addresses.

3.4 Camera Channels

Camera configuration is normally stored under:

/opt/kernelmind/apex/install/gmsl_quadcam/share/gmsl_quadcam/config/

Identify the file loaded by the camera service:

systemctl cat apex-camera.service
grep -Rns 'camera_sources' /opt/kernelmind/apex/install/gmsl_quadcam/share/gmsl_quadcam/config/

After technical support confirms the channel IDs, customers may change:

• camera_sources.head_left, head_right, hand_left, and hand_right: camera sources; use none for a channel that is not installed.
• flip_180_option (or flip_180 in older releases): image orientation.
• enable_compressed_pub: compressed-image publication.

CSI numbering can differ between controllers. Use a single-camera test instead of assuming a channel map. Camera intrinsics, exposure, trigger mode, and hardware synchronization are calibration settings and must not be changed by customers.

3.5 Recording Directory

Use BAG_STORAGE_ROOT in /etc/apex/apex.env to select an existing, mounted recording directory. Verify that it exists, is writable, and has sufficient space:

test -d "$BAG_STORAGE_ROOT" && test -w "$BAG_STORAGE_ROOT" && echo writable
df -h "$BAG_STORAGE_ROOT"

Recording and playback configuration is normally stored at:

/opt/kernelmind/apex/install/recording_playback_nodes_py/share/recording_playback_nodes_py/config/recording_playback.yaml

Only change topic allowlists and playback lists after confirming message-type and downstream compatibility. Gento replay may use a different chain from the standard recorder; do not mix the two configurations.

3.6 End-Effector Type

Use APEX_TOOL_TYPE to select the installed end effector. Confirm that its driver is installed and that only one end-effector control node is running. Do not run a manually started node while its service is active.

Motor IDs, position ranges, current limits, and end-effector Kp/Kd values must match the hardware and calibration data. Technical support must make those changes.

4. Apply Changes

Run systemctl list-unit-files 'apex-*' to verify the services installed on the device, then restart the services affected by the change:

Change	Services normally restarted
Product, model, or ROS domain	Robot and Teleop; also Camera or Tool when affected
Robot IP	Robot, followed by Teleop
Teleoperation or network settings	Teleop; also the release-specific network service when DHCP changes
Camera channels	Camera
Recording path or topic list	The service hosting recording, normally Teleop
End-effector type	Tool/end-effector service and Teleop

Common examples:

sudo systemctl restart apex-robot.service
sudo systemctl restart apex-teleop.service
sudo systemctl restart apex-camera.service

If the delivered system uses different service names, use the names found with systemctl cat. Do not create services from these examples.

5. Validate the Change

5.1 No-Motion Checks

source /etc/apex/apex_ros_env.sh

systemctl --no-pager --full status apex-robot.service apex-teleop.service
ros2 node list
ros2 topic echo /tj/info/robot_info --once
ros2 topic echo /tj/info/arm_state --once
ros2 topic echo /tj/info/robot_state --once
ros2 topic echo /tj/joint_states --once
ros2 topic hz /tj/joint_states

Check cameras and the end effector using the interfaces available on the delivered system:

systemctl --no-pager --full status apex-camera.service
ros2 topic list -t | grep '^/quad_tile/'
ros2 topic echo /quad_tile/jpeg/compressed --once
ros2 topic echo /tj/info/gripper_feedback_L --once

Some topics exist only on specific products or end-effector configurations.

5.2 Low-Risk Motion Checks

1. Clear the robot workspace and keep the emergency stop accessible.
2. Confirm that the UI, camera stream, and status feedback are normal.
3. Run Ready/Home and watch for errors or unexpected motion.
4. Begin with small single-arm motion, then test both arms. Test torso motion last on Gento.
5. Verify stop, restart, and disconnect recovery.

6. Settings Customers Must Not Change

The following items affect stability, safety limits, or calibration and may only be changed by trained engineers:

• Arm, torso, and gripper Kp/Kd, PD, feed-forward, and current limits.
• QP task weights, velocity limits, collision thresholds, collision pairs, and CoM/ZMP settings.
• Joint order, SDK mode enumeration, and control cycle.
• MJCF, SRDF, URDF, MvKDCfg, and other robot model files.
• Camera intrinsics, extrinsics, exposure, trigger, and hardware synchronization.
• systemd service definitions, launch files, and automatic-start scripts.

For these changes, provide technical support with the product model, controller, end-effector type, software versions, intended change, service logs, and a backup of the original configuration.

For startup, network, or device-detection issues, see FAQ and Quick Reference.
